CHARACTERISTIC BENEFITS
-
The upgrade from a traditional 80V lithium battery-powered truck to 153.6V significantly enhances overall energy efficiency. This is achieved by increasing motor power and reducing motor and controller currents.
The adoption of a permanent magnet synchronous motor, which is lighter than a comparable energy three-phase asynchronous motor, markedly improves comprehensive efficiency.
The truck is also equipped with standard load sensing, which prioritises steering and saves an additional 5% in energy.
-
The integration of the power system simplifies the wiring harness, substantially reducing the loss of electric energy during transmission.
The clarity and simplicity of the parts and control modules layout facilitate easier maintenance.
-
An emergency power-off switch is standard equipment, ensuring safety in emergencies.
The truck also features system-level voltage safety protection, including an integrated and optimally short voltage connection design and multiple insulation monitoring protections.
-
The truck is developed on the robust platform of internal combustion trucks, ensuring that all parts are mature and reliable.
It combines the high performance, stability, and environmental adaptability of internal combustion trucks with the eco-friendly benefits of lithium battery technology.
MODEL SPECIFICATIONS
-
Rated Capacity: 4000kg
Height (lowered/lifted): 2275/3000mm
Length (with/without fork): 4255/3185mm
Overall Width: 1480mm
Travel Speed (laden/unladen): 18/19km/h
Lift Speed (laden/unladen): 450/500km/h
-
Rated Capacity: 4500kg
Height (lowered/lifted): 2275/3000mm
Length (with/without fork): 4275/3205mm
Overall Width: 1480mm
Travel Speed (laden/unladen): 18/19km/h
Lift Speed (laden/unladen): 420/500km/h
-
Rated Capacity: 5000kg
Height (lowered/lifted): 2275/3000mm
Length (with/without fork): 4325/3255mm
Overall Width: 1480mm
Travel Speed (laden/unladen): 18/19km/h
Lift Speed (laden/unladen): 390/500km/h
